NetBackup
Netbackup 许可证
NetBackup8.1 license
KJXV-Y2R8-6V8Z-963Z-PPPP-VPOG-OZCP-PRPP-PPN3-4C
KRXW-WDSM-8R2R-W6PP-CRCR-PPZU-3SL4-P4PP-CR8P-N
NetBackup8.0 license
AJXW-K2BW-KJW2-PC8C-6P3Z-C877-7777-77H
DEX6-233N-DPNC-ZPP3-8ONO-4O4O-4OS7-7777-77U
DEXZ-KPPO-8TCN-434O-4O4O-4M77-7777-763R-PO8
DEX3-VRN2-3D2Z-UPPX-OXO4-O4O4-OS77-7777-7UN
DEX6-VC6N-WP8Z-WP34-O8O4-O4O4-O4M7-7777-776
DEXU-23OJ-BFNT-W8O4-O4O4-OS77-7777-7UN3-P83
DEX6-K83N-3CRP-OR3R-C8C4-O4O4-O4K7-7777-77E
DEX6-U26K-PT9C-ZO4O-4O4O-4M77-7777-763R-POP
DEXZ-DRP3-RTUN-N34O-4O4O-4M77-7777-763R-PO8
安装部署
安装 NBU Master
分区（使用60G硬盘）
[root@localhost ~]# fdisk /dev/nvme0n2
欢迎使用 fdisk (util-linux 2.37.4)。
更改将停留在内存中，直到您决定将更改写入磁盘。
使用写入命令前请三思。
设备不包含可识别的分区表。
创建了一个磁盘标识符为 0x0872d912 的新 DOS 磁盘标签。
命令(输入 m 获取帮助)：n
分区类型
p 主分区 (0 primary, 0 extended, 4 free)
e 扩展分区 (逻辑分区容器)
选择 (默认 p)：
将使用默认回应 p。
分区号 (1-4, 默认 1):
第一个扇区 (2048-125829119, 默认 2048):
最后一个扇区，+/-sectors 或 +size{K,M,G,T,P} (2048-125829119, 默认 125829119):
创建了一个新分区 1，类型为“Linux”，大小为 60 GiB。
命令(输入 m 获取帮助)：w
分区表已调整。
将调用 ioctl() 来重新读分区表。
正在同步磁盘。
[root@localhost ~]# mkfs.xfs -f /dev/nvme0n2
[root@localhost ~]# mkdir /data
[root@localhost ~]# echo "/dev/nvme0n2 /data/ xfs defaults 0 0" >> /etc/fstab && mount -a
创建相关用户和组
groupadd nbwebgrp
mkdir -p /usr/openv/wmc
useradd -g nbwebgrp -d /usr/openv/wmc nbwebsvc
groupadd nbusvc
useradd -g nbusvc -G nbwebgrp -d /home/nbusvc -m -s /bin/bash nbusvc
passwd nbusvc
[root@localhost ~]# cat /etc/group | grep nb
nbwebgrp:x:1001:
[root@localhost ~]# cat /etc/passwd | grep nb
nbwebsvc:x:1001:1001::/usr/openv/wmc:/bin/bash
解压上传到服务器的 NetBackup_10.1_LinuxR_x86_64.tar.gz 文件
[root@localhost ~]# cd /data/
[root@localhost data]# tar -zxvf NetBackup_10.1_LinuxR_x86_64.tar.gz
[root@localhost data]# ls -l NetBackup_10.1_LinuxR_x86_64
总用量 268
drwxr-xr-x. 2 root bin 41 8月 31 2022 Doc
-r-xr-xr-x. 1 root bin 193788 8月 31 2022 install
-r--r--r--. 1 root bin 25609 8月 31 2022 LICENSE
dr-xr-xr-x. 4 root bin 32 8月 31 2022 linuxR_x86
-r--r--r--. 1 root bin 16986 8月 31 2022 NBInstallAnswer-client.template
-r--r--r--. 1 root bin 11378 8月 31 2022 NBInstallAnswer-master.template
-r--r--r--. 1 root bin 14525 8月 31 2022 NBInstallAnswer-media.template
安装 libnsl 工具（NBU 的安装依赖这个工具）
cat << 'EOF' > /etc/yum.repos.d/aliyun_yum.repo
[ali_baseos]
name=ali_baseos
baseurl=https://mirrors.aliyun.com/centos-stream/9-stream/BaseOS/x86_64/os/
gpgcheck=0
[ali_appstream]
name=ali_appstream
baseurl=https://mirrors.aliyun.com/centos-stream/9-stream/AppStream/x86_64/os/
gpgcheck=0
EOF
dnf clean all && dnf makecache && dnf install libnsl -y
echo "192.168.40.139 master" >> /etc/hosts
echo "192.168.40.139 media" >> /etc/hosts
echo "192.168.40.139 master.lan.com" >> /etc/hosts
echo "192.168.40.139 media.lan.com" >> /etc/hosts
echo "192.168.40.139 nbwin1" >> /etc/hosts
echo "192.168.40.139 nbwin1.lan.com" >> /etc/hosts
执行安装
[root@localhost data]# ./NetBackup_10.1_LinuxR_x86_64/install
Veritas Installation Script
Copyright (c) 2022 Veritas Technologies LLC. All rights reserved.
Installing NetBackup Server Software
Do you wish to continue? [y,n] (y)
Is this host the master server? [y,n] (y)
Are you currently performing a disaster recovery of a master server? [y,n] (n)
Please enter the fully qualified path containing your customer registration key
file, or enter q to quit the install script.
/data/veritas_customer_registration_key.json
The NetBackup and Media Manager software is built for use on LINUX_RH_X86 hardware.
Do you want to install NetBackup and Media Manager files? [y,n] (y)
Enter license key: DEX3-VRN2-3D2Z-UPPX-OXO4-O4O4-OS77-7777-7UN
DEX3-VRN2-3D2Z-UPPX-OXO4-O4O4-OS77-7777-7UN:
NetBackup Enterprise Server Base product with all the features enabled
has been registered.
All additional keys should be added at this time.
Do you want to add additional license keys now? [y,n] (y) n
Would you like to use "localhost" as the configured
NetBackup server name of this machine? [y,n] (y) n
Enter the name of this NetBackup server: master
Enter the fully qualified name of a media server (q to quit): media.lan.com
Enter the fully qualified name of a media server (q to quit): q
......
File /usr/openv/tmp/install_trace.2105 contains a trace of this install.
That file can be deleted after you are sure the install was successful.
防火墙放行端口
firewall-cmd --permanent --add-port={1556/tcp,13724/tcp} && firewall-cmd --reload
[root@localhost data]# systemctl stop firewalld
[root@localhost data]# systemctl disable firewalld
NBU 维护命令
# 手动启动所有 NBU 服务
/usr/openv/netbackup/bin/bp.start_all
# 手动停止所有 NBU 服务
/usr/openv/netbackup/bin/bp.kill_all
# 启用PBX service,NBU JAVA GUI 需要用到
/opt/VRTSpbx/bin/pbx_exchange
# 维护license
[root@localhost data]# /usr/openv/netbackup/bin/admincmd/bpminlicense
DEX3-VRN2-3D2Z-UPPX-OXO4-O4O4-OS77-7777-7UN DEX3-VRN2-3D2Z-UPPX-OXO4-O4O4-OS77-7777-7UN 0x05000000 0x6936ae44 master
安装N BU Media
cat << 'EOF' > /etc/yum.repos.d/aliyun_yum.repo
[ali_baseos]
name=ali_baseos
baseurl=https://mirrors.aliyun.com/centos-stream/9-stream/BaseOS/x86_64/os/
gpgcheck=0
[ali_appstream]
name=ali_appstream
baseurl=https://mirrors.aliyun.com/centos-stream/9-stream/AppStream/x86_64/os/
gpgcheck=0
EOF
dnf clean all && dnf makecache && dnf install libnsl -y
fdisk /dev/nvme0n2
mkfs.xfs -f /dev/nvme0n2
mkdir /data
echo "/dev/nvme0n2 /data/ xfs defaults 0 0" >> /etc/fstab
mount -a
hostnamectl set-hostname media && bash
echo "192.168.40.139 master" >> /etc/hosts
echo "192.168.40.141 media" >> /etc/hosts
echo "192.168.40.139 master.lan.com" >> /etc/hosts
echo "192.168.40.141 media.lan.com" >> /etc/hosts
scp /data/NetBackup_10.1_LinuxR_x86_64.tar.gz root@192.168.40.141:/data/NetBackup_10.1_LinuxR_x86_64.tar.gz
tar -zxvf /data/NetBackup_10.1_LinuxR_x86_64.tar.gz -C /data/
[root@localhost ~]# /data/NetBackup_10.1_LinuxR_x86_64/install
Do you wish to continue? [y,n] (y)
Is this host the master server? [y,n] (y) n
Would you like to use "media" as the configured
NetBackup server name of this machine? [y,n] (y)
What is the fully qualified name of the master server? master
The NetBackup and Media Manager software is built for use on LINUX_RH_X86 hardware.
Do you want to install NetBackup and Media Manager files? [y,n] (y)
NetBackup and Media Manager are normally installed in /usr/openv.
Is it OK to install in /usr/openv? [y,n] (y)
访问使用
https://master/webui/login
username：==root==
password：==Root@2025==
